Line Scan Lens

Name: Line Scan Lens
Brand: EARTH TEKNIKS PRIVATE LIMITED
Price: 43500.0 INR
Availability: InStock

Price 43500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Line Scan Lens Specification

Usage
Machine Vision Systems

Function
Line Scan Imaging

Accuracy
High Resolution Imaging

Operating Mode
Continuous

Control Mode
Manual Focus

Standard
Industry Standard Optical Quality

Material
Aluminum Alloy Housing

Image Format
Up to 35mm Line Sensors

Aperture Range
f/2.8 to f/16

Weight
Approx. 250g

Compatibility
Compatible with Industrial Cameras

Lens Type
Line Scan Lens

Focal Length
50mm

Mount Type
C-Mount

Application
Inspection, Quality Control, Printing, Web Inspection

Optical Coating
Multi-Coated Glass Elements

Line Scan Lens Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About Line Scan Lens

Specially designed for 16K5 super high resolution
line scan camera
lens real resolution is upto 160lp/mm
Provide higher contrast for cameras
Max image circle is upto 82,
Compatible with 16K3.5/12K5 camera
Optical distortion is <1 pixel size
Magnification from 0.13X-4.5X

Precision Imaging for Industrial Applications

This Line Scan Lens is engineered for high accuracy in industrial environments, providing superb imaging for quality control, printing, and inspection tasks. Its industry-standard optical quality and compatibility with 35mm line sensors make it ideal for demanding applications. The multi-coated glass enhances imaging performance while the aluminum alloy housing ensures longevity even under rigorous usage.

Robust Design and Universal Compatibility

Built with a sturdy aluminum alloy body, the lens ensures reliable operation in challenging settings. The C-Mount interface allows quick integration with a wide array of industrial cameras. Manual focus control and continuous operating mode offer full command over image capture, making this lens adaptable for diverse machine vision systems found across India.

FAQ's of Line Scan Lens:

Q: How does a line scan lens differ from traditional lenses in industrial imaging?

A: A line scan lens is designed for capturing high-resolution images of objects moving continuously past the lens, rather than single snapshots. This makes it especially suitable for inspection, printing, and quality control processes, where detailed and seamless imaging along a line is essential.

Q: What is the process for installing and adjusting this Line Scan Lens with C-Mount cameras?

A: Installation is simple: align the C-Mount threads and screw the lens into place on your industrial camera. Once attached, adjust the manual focus ring to achieve the desired sharpness for your specific machine vision application. Ensure the lens is securely fixed before operation for best results.

Q: When should I use the f/2.8 aperture setting compared to f/16?

A: The f/2.8 aperture is ideal for low-light conditions or when a shallower depth of field is needed to isolate lines or features during inspection. Use f/16 when maximum depth of field and sharpness throughout the image are required for tasks like web inspection or large area quality control.

Q: Where is this lens best employed within industrial environments?

A: This line scan lens excels in environments requiring precise imaging, such as manufacturing assembly lines, printing facilities, and web inspection stations. It is widely used across multiple sectors in India that demand reliable quality control and inspection systems.

Q: What benefits does multi-coated glass provide in this lens?

A: The multi-coated glass elements significantly enhance image quality by reducing reflections, glare, and chromatic aberrations. This results in clearer, more accurate images, ensuring that inspection and quality control are performed with high fidelity and consistency.

Q: How does this lens support machine vision systems for quality control?

A: With high-resolution imaging, manual focus control, and compatibility with 35mm line sensors, the lens provides detailed, accurate images essential for detecting defects or inconsistencies. Its reliable performance helps streamline automated quality checks and boosts production efficiency.
